Test Type: Fizeau interferometry

TestBeam：Port1：Φ100mm;   Port2：Φ300mm

TestWavelength: 632.8nm(Semiconductor tunable laser)

Digital CCD: 1024×1024 pixel

Zoom:1X to 6X-Remote controlled

Alignment:Simple two spot alignment

Phase-shiftingModes: Wavelength tuning

Referencemirror：Port 1  PV：λ/20；Port2  PV：λ/15

Size:2400×1200×500mm

Weight:250Kg

Measuringof optical plane surface

Uniformity measurement of opticalmaterials

Dataanalysis and processing of interference fringes, Giving inspection report

Goodimaging quality and simple structure

Horizontalstructure

Easyto operate, easy to use

Wavelengthtuning analysis system
