Operationmode: Reflection / Transmission

Lightsource: White LED

Aperturediameter: Φ30mm

Anglemeasurement accuracy: 5"

Measuringrange: 0-180°

Ringgrating angle encoder resolution: 0.14"

Precisionof angle measuring turntable: radial and axial runout is less than or equal to0.02mm

Detectionresponse spectrum: 400 ~ 1100nm

Therefractive index measurement accuracy:1х10-4

Wedgeangle measurement

Angledifference of right angle prism

Flatnessmeasurement

Squarenessmeasurement

Refractiveindex measurement

Stablestructure with high precision turntable

Simplesoftware operation
