Workingmode: single tube reflex to heart measurement

Aperturediameter: Φ30mm

Testlight source: Green LED

Workingblind area: -50mm ~ 50mm

Maximumnumber of lenses to be measured: 10

Measuringrange: 50mm～+∝，-50mm～-∝

Measuringaccuracy: 2um/5"

Repeatability:+ 0.5um/ + 2"

Operatingtemperature: 20℃±2℃

Singlelens measurement

Gluedmirror measurement

Mirrorassembly

Curvatureradius detection

Equippedwith high precision turntable

Electriccontrol operation, easy adjustment
